Rpvc Pipes

Pilot Pipes

Pilot

Rpvc Pipes

product

Specification

  • Manufacturing of ISI mark PVC pipes from 20 MM to 315 MM in 4KG, 6KG, 8KG, and 10KG pressure class.
  • Lowest calcium percentage and highest grade chemicals gives long lasting pipes which are worth buying.
  • Available in pilot brands passed under strict quaility control.

Application

  • Agriculture: Irrigation schemes for agricultural purpose.
  • Domestic: Potable water supply scheme in Urban & Rural areas.
  • industrial: Disposal of chemical effuent, waste, Salt water handling.
  • Others: Bio-gas, natural gas distribution and oil distribution lines.

Attributes

  • Sturdy construction
  • Long service life
  • Anti corrosive in nature
  • High tensile strength

Salient Features

  • Light weight offers total economy in handling, Transportation & Installation.
  • Strong and Durable.
  • Energy saving.
  • Leak proof.
  • Strong and Durable.
  • Non corrosive.
  • Better flow characteristics.
  • Long lasting & maintenance free.
  • Convenient joining.

DIMENSION CHART OF ISI RIGDI PVC PIPES

O.D CLASS I 2.5 kgf/cm^2 CLASS II  4kgf/cm^2 CLASS III 6 kgf/cm^2 CLASS IV 10 kgf/cm^2
Min. Max. MIN Max. MIN Max. MIN Max.
20 ˍ ˍ ˍ ˍ ˍ ˍ 1.10 1.50
25 ˍ ˍ ˍ ˍ ˍ ˍ 1.40 1.80
32 ˍ ˍ ˍ ˍ ˍ ˍ 1.80 2.20
40 ˍ ˍ ˍ ˍ 1.40 1.80 2.20 2.70
50 ˍ ˍ ˍ ˍ 1.70 2.10 2.80 3.30
63 ˍ ˍ 1.50 1.90 2.20 2.70 3.50 4.10
75 ˍ ˍ 1.80 2.20 2.60 3.10 4.20 4.90
90 1.30 1.70 2.10 2.60 3.10 3.70 5.00 5.70
110 1.60 2.00 2.50 3.00 3.70 4.30 6.10 7.10
140 2.00 2.40 3.20 3.80 4.80 5.50 7.70 8.90
160 2.30 2.80 3.70 4.30 5.40 6.20 8.80 10.20
180 2.60 3.10 4.20 4.90 6.10 7.10 9.80 11.40
200 2.90 3.40 4.60 5.30 6.80 7.90 11.00 12.70
225 3.30 3.90 5.20 6.00 7.60 8.80 12.40 14.30
250 3.60 4.20 5.70 6.50 8.50 9.80 13.80 15.90
280 4.10 4.80 6.40 7.40 9.50 11.00 15.40 17.80
315 4.60 5.30 7.20 8.30 10.70 12.40 17.30 19.90
